Home > Products > Rubber Auxiliary Agent > Master batch making machine

Master batch making machine

Master batch making machine

Product Description

1. Technical data

1. Screw diameter: 50.5mm

2. L/D: 40

3. Screw and barrel: anti-wear

4. Motor power: 45-55KW (SIEMENS)

5. Screw rotation speed: 500RPM

6. Heating power: 37KW

7. Output: 200-300KG/H (according to your raw material and formula)

Master batch making machine


2. Machine configuration

No.

Name & description

Unit

Remark

1

SHR200A high speed mixer and screw charger

1 Set

200L high speed mixer

2

Twin screw metering feeder

1 Set

2.1

Feeder

1 set

1.5KW AC motor, SIEMENS inverter

2.2

Vertical mixing device

1 set

Anti bridging device

3

Twin screw extruder

3.1

Twin screw extruder

1 set

3.2

Vacuum system

1 set

1.5KW AC

3.3

Soft water cooling system

1 set

0.55KW AC

3.4

Hydraulic screen changer

1 set

1.5KW AC

4

Electric control cabinet

1 set

5

Spare parts

1 set

6

Documents

1 copy

Compounding Extruder Line

Process

Representative materials

Mixing nature-changing

PE,PP,PS+SBS,PA+EPDM,PP+NBR,EVA +Silicon rubber, etc.

PE,PA,PC,CPE+ABS(alloy),PBT+PET,PP+ PE etc.

Filling nature-changing

PE,PP,EVA, etc.+ Calcium carbonate, talcum powder, titanic powder

ABS,PC,PS, etc.+ aluminum hydroxide, magnesium hydroxide, antimony oxide.

PP,PA,ABS +ferrous powder, sulphuric powder ceramic powder

Functional machine pellets

PP,PA,ABS,PBT, etc+ anti-burning agent and other auxiliary agents: combustion-supporting machine pellets

PE,PP,PS, etc+ starch: de-composing machine pellets

PE+ fog-preventing dipper, stabilizer: dual-prevention machine pellets

PE,EVA=ABS etc+ carbon black: black machine pellets

Colored machine pellets

PE,PP,ABS,AS,PA,EVA,PET +pigment and auxiliary

Intensified glass fibers and carbon fibers

PP,PBT,ABS,AS,PA,PC,POM,PPS,PET etc.+ long fibers, small fibers, carbon fibers, crystals and so on, etc.

Various cables

HDPE,LDPE,LLDPE,MDPE,EVA,PVC,PP, etc. insulating cables,coatings,

PE peroxide silicon alkyl crossing cables: radialization crossing cables

Special materials

EVA heat-melting glue, polyurethane, fluorine rubber, fluorine plastics, PP cigarette filtering material and TPR sole material

Reaction extruding

Poly-amide condensate, poly-amide melting polymerization, poly-amide polythene-adding, poly-carbonate condensate, etc.

Exhausting and volatilization

Polystyrene oxide, high-absorbing resin, chlorine sulphur polyethylene

Powder paint

Polyester, ring oxide, lactide, polyurethane, acrylate

Masterbatch Extruder Line



FAQ

Q1: Are you a factory or trading company ? How is you factory extrusion experience?
A: We are factory in Nanjing , 20 years experience on extrusion.Leading supplier in Nanjing city.

Q2:Where is your factory located? How can I visit there?

A : Our factory is based in 77 Tangtong Rd,Hushu,Jiangning District Nanjing , Jiangsu Province, China,

1) You can fly to Nanjing Lukou Airport or you can fly to Shanghai then take high-speed train to Nanjing South Railway Station.

2) We will arrange the pick up in Nanjing Lukou airport or South Railway Station

Q3:What can you provide for after sale service?

A:We can send engineers to your factory for installation and training if customers‘ required

Q4:If we have very special request for the production line,could you help me to do the design?

A:Experienced mechanical designer customized-design provided.

Q5:Could you afford technician team to guide ours installation and commissioning?

A:Experience engineer oversea installation service provided.

Q6: Why choose you ?

A: 1) Quick response. Once we got the inquiries from you, we will reply you within 12hours.

2) Promising leading time. To guarantee the quality, the machine will be finished within max 20days.

3) Before leaving factory, all the machine will be fully tested.

4) Customized package(Wooden) will ensure a safety shipping.

Twin Screw Extruder Specifications


Twin Screw Extruder Specifications1


Nanjing Juli Chemical Machinery Co., Ltd.

 Nanjing Juli Chemical Machinery Co., Ltd. is a specialized manufacturer of professional designing and making co-rotating parallel twin-screw extruders, granule equipment and spare parts. Our factory manufactures complete set of plastic extrusion equipment, and provides related crafts, technical development, and advisory service.

Company Info

  • Company Name: Nanjing Juli Chemical Machinery Co., Ltd.
  • Representative: Sun Houen
  • Product/Service: Screw Extruder , Twin Screw Extruder , Plastic Granules Machine , Plastic Pelletizing Line , Double Screw Extruder , Single Screw Extruder
  • Capital (Million US $): 16,000,000RMB
  • Year Established: 2005
  • Total Annual Sales Volume (Million US $): Below US$1 Million
  • Export Percentage: 31% - 40%
  • Total Annual Purchase Volume (Million US $): Below US$1 Million
  • No. of Production Lines: 46
  • No. of R&D Staff: 5 -10 People
  • No. of QC Staff: Fewer than 5 People
  • OEM Services Provided: yes
  • Factory Size (Sq.meters): 10,000-30,000 square meters
  • Factory Location: 77 tangtong road, jiangning district, nanjing city, jiangsu province, China
  • Contact Person: Ms. Sophia Tsai
  • Tel: 00-86--18994102661
